The drift geology under Wolverhampton shifts dramatically within half a mile. Head deposits and glacial till overlie the Wildmoor Sandstone across much of the city, creating sharp stiffness contrasts that go unnoticed until a cone hits refusal at 2.4 metres. In our lab, we analyse CPT data from the Wolverhampton area weekly, and the most frequent call we get is about premature refusal in dense boulder clay near the 52.58° N corridor. A Cone Penetration Test run with a 20-tonne truck and a 200 mm pusher gives continuous tip resistance (qc) and sleeve friction (fs) profiles that SPT simply cannot match. When the client needs pore pressure dissipation data for clay layers, we add a piezocone and run the test to BS EN ISO 22476-1. For sites near the Staffordshire Canal, where made ground reaches 3–4 metres, pairing CPT with test pits lets us log the fill lithology before pushing through the natural strata below.
Continuous CPT profiling reveals the thin sand lenses inside Wolverhampton’s glacial till that govern drainage and consolidation time.
Method and coverage
Regional considerations
Sites in Tettenhall sit on thick, free-draining sandstones where cone resistance can jump from 5 MPa to 25 MPa across a weathered contact; misreading that boundary leads to over-designed piles or unsafe spread footings. Move south toward Bilston and the ground changes entirely: coal measures and mine workings introduce voids and collapse risk that a CPT log alone cannot flag. We see engineers relying on CPT refusal as a proxy for rockhead, but in Wolverhampton’s Permo-Triassic sandstone the cone can stop on a cobble inside the till, giving a false rock elevation. That is why we always recommend cross-referencing the CPT profile with rotary coreholes or at least a few dynamic probe points. Dissipation tests in the clay layers are another critical step: the consolidation coefficient derived from t50 data controls the rate of settlement, and underestimating it has delayed more than one Midlands project. A thorough CPT campaign in this city must account for both the natural variability of the drift and the legacy of deep mining.
Standards that apply
BS EN ISO 22476-1:2012 - Geotechnical investigation and testing. Field testing. Electrical cone and piezocone penetration test, BS EN 1997-2:2007 - Eurocode 7. Geotechnical design. Ground investigation and testing, BS 5930:2015+A1:2020 - Code of practice for ground investigations, ISO/IEC 17025:2017 - General requirements for the competence of testing and calibration laboratories
Complementary services
Piezocone Penetration Test (CPTu)
Full qc, fs, and u2 measurement with dissipation tests at specified horizons. Ideal for Wolverhampton's clay-rich till and alluvial pockets where consolidation parameters are needed for settlement analysis.
CPT with Soil Sampling Correlation
Combined CPT and window sampling boreholes on the same grid. We run the cone first to identify strata boundaries, then target U100 or bulk samples exactly where the Robertson chart indicates cohesive behaviour.
Typical parameters
Top questions
How much does a CPT test cost in Wolverhampton?
A standard CPT push in the Wolverhampton area typically ranges from £130 to £180 per metre, depending on access conditions, depth, and whether piezocone (CPTu) is required. Mobilisation is charged separately and depends on distance from our West Midlands base.
What depth can a CPT reach in Wolverhampton's ground?
In the sandstone areas to the west of the city we routinely reach 18–25 metres with a 20-tonne truck. In the boulder clay around the city centre, refusal often occurs between 8 and 14 metres. We always discuss expected refusal depth based on nearby BGS borehole records before quoting.
Which standard do you follow for CPT reporting?
All our CPT data is acquired and reported to BS EN ISO 22476-1 Class 2, with AGS 4 digital files delivered alongside the PDF log. The interpretation follows BS EN 1997-2 and uses the Robertson (1990) soil behaviour type chart.
Do I need a separate borehole if I run CPT?
The reference range for this service in Wolverhampton is £130 - £180. The final price depends on the project scope and volume.
